| Place of Origin: | China |
|---|---|
| Brand Name: | Bozhong |
| Certification: | IOS,SGS |
| Model Number: | SUS 347 |
| Minimum Order Quantity: | 500KG |
| Packaging Details: | Standard Seaworthy Package |
| Delivery Time: | 7-25DAYS ACCORDING TO YOUR ORDER QUANTITY |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 1000 TONS PER MONTH |
| Model NO.: | 347 | Special Use: | Measuring Tools, Cutters In Common Steel |
|---|---|---|---|
| Surface: | 2B/BA/No.4/Mill Edge/Slit Edge | Shape: | Sheet/ Coils/Strips |
| Thickness: | 0.3~180mm Thickness | HS Code: | 7219220000 |
| Process: | Cold / Hot Rolled | ||
| Highlight: | 1.4550 SS Steel Plate,347 SS Steel Plate |
||
SUS 347, 0Cr18Ni11Nb Stainless Steel Plates/Sheets 347 1.4550
This data sheet applies to stainless steel 347 / 1.4550 hot and cold rolled sheet, strip and bars, semi-finished products, rods and sections as well as for seamless and welded steel tubes for mechanical and general engineering purposes.
For construction parts which should be resistant to scaling up to about 1050°C and extensively inured to the effect of sulfurous gases, especially above 900°C, is very low.
| Element | % Present (in product form) |
|---|---|
| Carbon (C) | 0.08 |
| Silicon (Si) | 1.00 |
| Manganese (Mn) | 2.00 |
| Phosphorous (P) | 0.045 |
| Sulfur (S) | 0.015 |
| Chromium (Cr) | 17.00 - 19.00 |
| Nickel (Ni) | 9.00 - 12.00 |
| Niobium (Nb) | 10xC to 1.00 |
| Iron (Fe) | Balance |
| Product Form | ||||||||
|---|---|---|---|---|---|---|---|---|
| C | H | P | L | L | TW / TS | |||
| Thickness (mm) Max | 8 | 13.5 | 75 | 160 | 2502) | 60 | ||
| Yield Strength | Rp0.2 N/mm2 | 2203) | 2003) | 2003) | 2054) | 2056) | 2055) | |
| Rp1.0 N/mm2 | 2503) | 2403) | 2403) | 2404) | 2406) | 2405) | ||
| Tensile Strength | Rm N/mm2 | 520 - 7203) | 520 - 7203) | 500 - 7003) | 510 - 7404) | 510 - 7406) | 510 - 7405) | |
| Elongation min. in & | A1) %min (longitudinal) | - | - | - | 40 | - | 35 | |
| A1) %min (transverse) | 40 | 40 | 40 | - | 30 | 30 | ||
| Impact Energy (ISO-V) ≥ 10mm thick | Jmin (longitudinal) | - | 100 | 100 | 100 | - | 100 | |
| Jmin (transverse) | - | 60 | 60 | - | 60 | 60 | ||
| Density at 20°C kg/m3 | 7.9 | |
|---|---|---|
| Modulus of Elasticity kN/mm2 at | 20°C | 200 |
| 200°C | 186 | |
| 400°C | 172 | |
| 500°C | 165 | |
| Thermal Conductivity W/m K at 20°C | 15 | |
| Specific Thermal Capacity at 20°C J/kg K | 500 | |
| Electrical Resistivity at 20°C Ω mm2 /m | 0.73 | |
