| Place of Origin: | China |
|---|---|
| Brand Name: | Bozhong |
| Certification: | ISO / TUV / DNV |
| Model Number: | 317 / 317L /316J1 / 316J1L |
| Minimum Order Quantity: | negotiable |
| Price: | negotiable |
| Packaging Details: | seaworthy packing or as required |
| Delivery Time: | 3--10days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000TON/MONTH |
| Description: | Stainless Steel Sheet | Grade: | 317 / 317L /316J1 / 316J1L |
|---|---|---|---|
| Standard: | AISI, ASTM, DIN, EN, GB ,JIS | Dimension: | Accept Custom |
| MOQ: | 1000 Kg | Other Name: | SS Steel Plate |
| High Light: | stainless steel sheet,stainless steel flat plate |
||
With wide experience and expertise, Bozhong Group is one of the leading stainless steel sheet/plate manufacturers and suppliers. We have hundreds of high-qualified workers at your service. Please rest assured to get the competitive price of stainless steel sheet/plate for sale with us.
Standard: ASTM, JIS, AISI, GB, DIN, EN
Type 317(uns 31700 1.4449) is an austenitic chromium-nickel stainless steel with excellent corrosion resistance; Its high Molybdenum content enhances the grade's superior pitting resistance. It is the most corrosion resistant of the 300 Series alloys and possesses the highest tensile and creep strength properties at elevated temperatures.
Alloy 317L (UNS S31703 1.4438 ) is a molybdenum-bearing austenitic stainless steel with greatly increased resistance to chemical attack as compared to the conventional chromium-nickel austenitic stainless steels such as Alloy 304. In addition, Alloy 317L offers higher creep, stress-to-rupture, and tensile strength at elevated temperatures than conventional stainless steels. It is a low carbon or "L" grade which provides resistance to sensitization during welding and other thermal processes. X2CrNiMo18-15-4
Materials:
300series:301,304,304L,309,309s,310,310S,316,316L,316Ti,317L,321,347,
| Grade | Chemical Component % | |||||||||||
| C | Cr | Ni | Mn | P | S | Mo | Si | Cu | N | Other | ||
| 316 | 0Cr17Ni12Mo2 | ≤0.08 | 16.00-18.50 | 10.00-14.00 | ≤2.00 | ≤0.035 | ≤0.030 | 2.00-3.00 | ≤1.00 | - | - | - |
| 316L | 00Cr17Ni14Mo2 | ≤0.030 | 16.00-18.00 | 10.00-14.00 | ≤2.00 | ≤0.035 | ≤0.030 | 2.00-3.00 | ≤1.00 | - | - | - |
| 316N | 0Cr17Ni12Mo2N | ≤0.08 | 16.00-18.00 | 10.00-14.00 | ≤2.00 | ≤0.035 | ≤0.030 | 2.00-3.00 | ≤1.00 | - | 0.10-0.22 | - |
| 316Ti | 00Cr17Ni13Mo2N | ≤0.080 | 16.00-18.50 | 10.00-14.00 | ≤2.00 | ≤0.035 | ≤0.030 | 2.00-3.00 | ≤1.00 | - | Ti(5C-0.75%) | |
| 316J1 | 0Cr18Ni12Mo2Cu2 | ≤0.08 | 17.00-19.00 | 10.00-14.50 | ≤2.00 | ≤0.035 | ≤0.030 | 1.20-2.75 | ≤1.00 | 1.00-2.50 | - | - |
| 316J1L | 00Cr18Ni14Mo2Cu2 | ≤0.030 | 17.00-19.00 | 12.00-16.00 | ≤2.00 | ≤0.035 | ≤0.030 | 1.20-2.75 | ≤1.00 | 1.00-2.50 | - | - |
| 317 | 0Cr19Ni13Mo3 | ≤0.12 | 18.00-20.00 | 11.00-15.00 | ≤2.00 | ≤0.035 | ≤0.030 | 3.00-4.00 | ≤1.00 | - | - | - |
| 317L | 00Cr19Ni13Mo3 | ≤0.08 | 18.00-20.00 | 11.00-15.00 | ≤2.00 | ≤0.035 | ≤0.030 | 3.00-4.00 | ≤1.00 | - | - | - |
| 1Cr18Ni12Mo3Ti6 | ≤0.12 | 16.00-19.00 | 11.00-14.00 | ≤2.00 | ≤0.035 | ≤0.030 | 2.50-3.50 | ≤1.00 | - | - | Ti5(C | |
Thickness:
Cold rolled:0.1mm-6mm or as customers requirement
Hot rolled: 3.0mm-180mm or as customers requirement
Width: 1000/1219/1500/1800mm/2000mm or as customers requirement
Length: as customer requirement
Surface: 2B, BA, No.1,No.4,HL,No.8,Mirror etc Mirror, No.4, HL NSP, Bead Blast, Vibration,
HL Gold, Mirror Gold, Vibration Gold NSP No.4 Copper NSP, Mirror Copper, Bead Copper,
HL Brass, Mirror Brass, Bead Brass, HL Black, Mirror Black, Bead Black NSP,
HL Bronze, Mirror Bronze, Vibration Bronze,Mirror Etched, HL Etched Copper, Mirror Black Etched, Mirror Etched Gold.
Application:
• Escalator, Elevator, Doors
• Furniture
• Production tools, Kitchen appliances, freezers, cold rooms
• Auto Parts
• Machinery and Packaging
• Equipment and Medical devices
• Transport system
Packing:
Packed and labeled according to the regulations and customer's requests.Great care is taken to avoid any damage which might otherwise be caused during storage or transportation.
With wide experience and expertise, Bozhong Group is one of the leading stainless steel sheet manufacturers and suppliers. We have hundreds of high-qualified workers at your service. Please rest assured to get the competitive price stainless steel sheet for sale with us.
