| Brand Name: | BOZHONG |
|---|---|
| Certification: | ISO / TUV / DNV |
| Model Number: | Stainless Steel 304 316L 3A Welded Tee |
| Minimum Order Quantity: | negotiable |
| Price: | negotiable |
| Packaging Details: | seaworthy packing or as required |
| Delivery Time: | 3--10days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000TON/MONTH |
| Description: | Stainless Steel 304 316L 3A Sanitary Reducing Welded Tee | GRADE: | 304 316L 3A |
|---|---|---|---|
| Technics: | Forged | Finish: | Varnish Paint |
| Pressure Rating: | 2000LBS | Standard: | DIN |
| High Light: | 304 forged stainless steel fittings,316L forged stainless steel fittings,Sanitary butt weld reducing tee |
||
304 316L Forged Stainless Steel Fittings / 3A Sanitary Reducing Welded Tee
Our Advantages:
1. High-quality products as per certificate ISO 9001
2. Good services to satisfy you.
3. Timely delivery for your orders.
4. Samples are available as per your request.
5. we got prime hot rolled stainless steel material from TsingShan Steel Corp.
A tee is also called a triplet. It has three joints (just like the shape of T) and it can be used to either combine or split a fluid flow. Most of the common tees are of the same inlet and outlet sizes, but reducing tees (one joint is obviously smaller than the other two) are available as well. Due to its diverse dimension, tees are capable to control the volume when required.
Specification of Stainless Steel Tee:
Name |
Specification | Type | Data |
| Stainless Steel Butt Weld Tee | Size | Butt Welded Straight Tee | NPS1/2 inch-NPS48 inch |
| Butt Welded Reducing Tee | NPS1/2 inch-NPS48 inch | ||
| Material | ASTM 304, 304L, 316, 316L, 321, etc. | ||
| Standard | ANSI B16.9, MSS SP 43, DIN 2615, etc. | ||
| Stainless Steel Socket Weld Tee | Size | Socket Weld Tee | 1/8 inch-4 inch; DN6-DN100 |
| Material | ASTM 304, 304L, 316, 316L, 321, etc. | ||
| Standard | ANSI B16.9, MSS SP 43, DIN 2615, etc. | ||
| Stainless Steel Threaded Tee | Size | Threaded Tee | 1/8"-4"; DN6-DN100 |
| Material | ASTM 304, 304L, 316, 316L, 321, etc. | ||
| Standard | ANSI B16.9, MSS SP 43, DIN 2615, etc. | ||
Specification of Straight Tee:
1.Item: Butt Welded Straight Tee
2.Specification: NPS1/2 inch-NPS48 inch
3.OD (D): 21.3 - 1219
4.Center to End (C): 25 -889
5.Center to End (M): 25 - 838
6.Material: ASTM 304, 304L, 316, 316L, 321, etc.
7.Standard: ANSI B16.9, MSS SP 43, DIN 2615, etc.
Specification of Reducing Tee:
1. Item: Butt Welded Reducing Tee
2. Specification: NPS1/2 inch-NPS48 inch
3. OD (D): 26.7 - 1219
4. OD(D1): 21.3 - 1168
5. Center to End (C): 29 - 889
6. Center to End (M): 29 - 838
7. Material: ASTM 304, 304L, 316, 316L, 321, etc.
8. Standard: ANSI B16.9, MSS SP 43, DIN 2615, etc.
MC products are designed and built to meet the most stringent requirements of ultra-pure processing, including the special specifications for dimensions, surface finishes and tolerances. Our Pipe cross fittings are ideal for pharmaceutical, biotechnological and other ultra-pure applications.
Specifications of Stainless Steel Socket Weld Tee:
1. Size: 1/8 inch-4 inch; DN6-DN100
2. Pressure: 3000#, 6000#, 9000#
3. Standard: GB/T14383-2008
SH/T3410-1996(DN=10-80mm SCH80, sCH160)
HG/T21634-1998
ASME B16.11-2005
BS3799-1974
JIS B2316-2007
4.Manufacture process: Forging or machining
5.Material: 304-304H-304L-304N-304LN 316-316H-316L-316N-316LN 321-321H-347-347H
SMC products are designed and built to meet the most stringent requirements of ultra-pure processing, including the special specifications for dimensions, surface finishes and tolerances. Our Pipe cross fittings are ideal for pharmaceutical, biotechnological and other ultra-pure applications.
Specifications of Stainless Steel Threaded Tee:
1. Size: 1/8"-4"; DN6-DN100
2. Pressure: 2000#, 3000#, 6000#
3. Standard: GB/T 14383, ASME B16.11, BS 3799
4. Manufacture Process: Forging or machining
5. Material: 304, 304L, 316, 316L, etc.
6. Package: wooden case, wooden pallet
Application of Stainless Steel Butt Welded Tee:
Electricity, Petroleum, Gas, Petrifaction, Chemical Industry, Ship, Heating, Papermaking, Metallurgy
1. SW Fittings are family of high pressure fittings are used in various industrial processes.
2. They are used for lines conveying flammable, toxic or expensive material where no leakage can be permitted, and for steam 300 to 600 PSI.
3. They are used only in conjunction with ASME Pipe and are available in the same size range.
4. They are used in areas where pipe-work is permanent and are designed to provide good flow characteristics.
5. They are produced to several ASTM standards and are manufactured in accordance with ASME B16.11. The B16.11 standard covers pressure-temperature ratings, dimensions, tolerances, marking, and material requirements for forged carbon and alloy steel. Acceptable material forms are forgings, bars, seamless pipe, and seamless tubes which conform to the fittings chemical compositions, melting practices, and mechanical property requirements of ASTM A105, A182, or A350.
6. They are available in three pressure ratings: 3000lbs, 6000lbs and 9000lbs.
Package of Stainless Steel Pipe Fitting:
The stainless steel pipe fitting products are packed according to the international standards and regulations as well as to customer's requests. We would take great care to avoid any damage during storage or transportation of the stainless steel flanges.
