We are one of the most quality conscious producers of the wide range of flanges which is meant to cater to various industrial platforms in various domains. The applications of this product can be traced to numerous industrial domains which is highly convenient for our clients.
The raw materials used to manufacture and fabricate these highly in- demand products are known to be acquiredexperienced industrial distributors dealing in these products for a fairly long period of time. We study and analyze behavioral patterns and the quality levels of the vendors providing raw materials which helps to choose the best resources to be used in the manufacturing process. The technological superiority of our manufacturing product enables us to deliver our clients with prompt and flawless service.
Apart the latest technology, we also ensure high levels of tensile and ductile strength which is highly beneficial. Our experts monitor and make sure that these products are tested for its hardness and dimensional accuracy. This product does not cater to rust and plays an important role in resisting all kinds of industrial obstacles. The prices that we offer this product is the least one can expect and the quality aspect of it is simply exquisite which speak volumes of the total dimensional accuracy of the product.
Flange Standards:
ANSI/ASME Standard: ANSI B16.5, ANSI B16.47 Series A & B, MSS-SP-44, API 605, API6A in class 150 to 2500;
AWWA C207 flanges in Class B, Class D, Class E, Class F, Ring, Blind & Hub;
European DIN, UNI, EN 1092-1, BS 4504, ISO, NS, NFE29203 flanges in Pressure PN6 to PN100;
Japanese JIS B2220 & Korean KS B1503 flanges in pressure 5K to 40K;
Russian GOST 12820-80, GOST 12821-80, GOST 12815-80 in pressure PN0.6MPa to PN10MPa;
South African SABS 1123 / SANS 1123 in Class 600kPa to 4000kPa.
Flange Materials:
Aluminum
ASTM B210,B234,B241,B247,B361.BS 1490,EN754,EN1706,EN12392
1060,3003,3004,3102,5052,5083,5086,5454,6005,6060,
6061,6063,6066,6560,7005,7072,7075
LM0-LM26,
Copper,Brass,Bronze
ASTM B16,B176,B369,B584,EN1652,EN12163,,EN12451,EN13605,DIN17672,etc
ASTM B62,B103,B139,B148,B271,B505,B584,B763,BS1400,DIN 1705
C83600,C83900,C84200,C84800,C86200,C86500
CZ106 (CW505L),CZ108 (CW508L)CZ112 (CW712R),CZ114 (CW721R), CZ115 (CW722R),CZ120 (CW612N),
CZ121 (CW614N),CZ122 (CW617N),CZ126 (CW707R), CZ130 (CW624N),CZ131 (CW606N),CZ132 (CW602N)
AB2,BS B23,CA104,C63000,C63200,DEF STAN 02-833 NES833
Leaded Bronze SAE660,SigmaBronze 7,
Phosphor Bronze BS1400 PB1, PB102,PB104,C51000,C54450
Nickel alloy
ASTM B160,B161,B162,B366,B564,B574,B575,B622,DIN17751
UNS N04400,N04405,N06600,N06617,N06625,N08800,N06022,
N10276,N10665,K92890,N08330.N06455,N07090,N07263
Titanium
ASMESB265,SB338,SB861,SB348,SB381,ISO5832
Gr1,Gr2,Gr3,Gr4,Gr5,Gr7,Gr9,Gr11,Gr12,Gr23,Gr3M.
Duplex material
ASTM A182, A240, A276, A479, A480, A798, A790, A815, A928, A988.
F44 (UNS S31254) ,F51(UNS S31803),F53(UNS S32750), F55 (UNS S32760)
Above is common material, we can fulfill all brand according to ASTM,EN standard,etc
0
Flange Face Type:
Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Flange Norminal Diameter Range:
1/2” – 96”, DN15-DN2000
Normail Pressure Range:
150# - 2500#
PN6 – PN100
600kPa - 4000kPa
5K - 40K
