| Place of Origin: | China |
|---|---|
| Brand Name: | BOZHONG |
| Certification: | ISO, SGS,BV,TUV,3.1 |
| Model Number: | 16Mo |
| Minimum Order Quantity: | 1000KG |
| Price: | USD.9-1.9/KG FOB SHANGHAI |
| Packaging Details: | Standard Seaworthy Package |
| Delivery Time: | 7-35DAYS ACCORDING TO YOUR ORDER QUANTITY |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 10000TONS PER MONTH |
| Product Name: | Chrome Molybdenum Alloy Steel Plate Sheet ； | Standard: | ASME ；EN10028 |
|---|---|---|---|
| Grade: | 16Mo3 | Delivery Condition: | Furnace Normalised ; Hot Rolled |
| Plate Processing: | Cutting Forming Drilling/ Machining Grinding Testing | Thickness: | 5mm；10mm-150mm |
| Width: | 1,500mm To 2,500mm | Length: | 6,000mm To 12,000mm |
| High Light: | EN10028 Alloy Steel Plate,16MO3 Alloy Steel Plate,ASME chrome moly steel plate |
||
EN10028 16MO3 Chrome Molybdenum Alloy Steel Plate ASME Standard
Alloy Steel Plate
16mo3 is a EN10028 specified pressure vessel grade chrome molybdenum steel alloy for use in elevated working temperatures. 16mo3 steel is a pressure vessel steel that is used in applications with elevated temperatures according to EN 10028 2. It has improved mechanical properties and better creep resistance allowing it to be used up to 500°C. This makes it ideal for a wide range of uses where the plates will have to perform at a high temperature continuously
16mo3 material is used as a weldable steel in the fabrication of industrial boilers and steel pressurised vessels found in the oil, gas and chemical industry. Due to the materials chrome and molybdenum content, 16Mo3 has excellent heat resistance and corrosion resistant characteristics.
Typical applications for 16Mo3 include a wide range of power plant equipment, industrial exhaust, venting and flare systems and waste recycling and incineration plants. It is also valuable for machinery where parts are likely to remain hot for an extended period.
In power plants it is regularly used in boilers, superheater tubes, collector and hot steam Pipes, stove tubes and conduits. 16Mo3 is also used in various types of heat exchanger in both the upstream and downstream oil and gas industry
16MO3 Alloy Steel Plate EQUIVALENTS
Thickness from 5mm to 200mm
Width: from 1,500mm to 2,500mm
Length: from 6,000mm to 12,000mm
Chemical Properties of 16mo3 Alloy Steel Plate
| Grade | C | Si | Mn | P | S | Cr | Mo | Ni | Nb | Ti | V | Al | N | Cu |
| 16Mo3 | 0.12/0.20 | 0.35 | 0.40/0.90 | 0.025 | 0.010 | 0.030 | 0.25/0.35 | 0.30 | – | – | – | – | 0.012 | 0.30 |
| Grade | Thickness | Temperature (° C) | |||||||||
| 50° | 100° | 150° | 200° | 250° | 300° | 350° | 400° | 450° | 500° | ||
| (mm) | MPa | MPa | MPa | MPa | MPa | MPa | MPa | MPa | MPa | MPa | |
| 16Mo3 | ≤16 | 273 | 264 | 250 | 233 | 213 | 194 | 175 | 159 | 147 | 141 |
| >16 ≤40 | 268 | 259 | 245 | 228 | 209 | 190 | 172 | 156 | 145 | 139 | |
| >40 ≤60 | 258 | 250 | 236 | 220 | 202 | 183 | 165 | 150 | 139 | 134 | |
| >60 ≤100 | 238 | 230 | 218 | 203 | 186 | 169 | 153 | 139 | 129 | 123 | |
| >100 ≤150 | 218 | 211 | 200 | 186 | 171 | 155 | 140 | 127 | 118 | 113 | |
| >150 ≤250 | 208 | 202 | 191 | 178 | 163 | 148 | 134 | 121 | 113 | 108 | |
