| Brand Name: | BOZHONG |
|---|---|
| Certification: | ISO / TUV / DNV |
| Model Number: | C276 Stainless Steel Pipe Fitting |
| Minimum Order Quantity: | negotiable |
| Price: | negotiable |
| Packaging Details: | seaworthy packing or as required |
| Delivery Time: | 3--10days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000TON/MONTH |
| Description: | C276 Stainless Steel Pipe Fitting | GRADE: | C276 |
|---|---|---|---|
| Density: | 8.89 G/cm3 | Wall Thickness: | Sch 5-sch160,xxs |
| High Light: | butt weld fittings,ss pipe fittings |
||
|
Introduction Inconel is a group of austenitic nickel-chromium-based super alloys produced by Special Metals Corporation. Super alloys are referred to as high performance alloys that function well in environments with elevated temperatures. Super alloy INCONEL C-276 has high molybdenum content which provides the material with localized corrosion resistance like pitting. This alloy is generally known for corrosion resistance in a wide range of aggressive media. The low carbon content in this alloy helps to reduce carbide precipitation while performing welding. The following section explains in detail about super alloy INCONEL C-276. Chemical Composition The chemical composition of INCONEL C-276 is outlined in the following table.
Physical Properties The physical properties of INCONEL C-276 are tabulated below.
Mechanical Properties The following table shows mechanical properties of INCONEL C-276.
Thermal Properties The thermal properties of INCONEL C-276 are tabulated below.
Fabrication and Heat treatment Welding Weldability of INCONEL alloy C-276 is rated as good. This material can be used as-welded for most applications. Hot Working Hot working of this alloy can be performed 870 and 1230°C (1600 and 2250°F). in case of performing heavy working, it has to be above 1090°C (2000°F). Annealing INCONEL alloy C-276 can be annealed at 1150-1175°C (2100-2150°F) and rapidly cooled by water quenching. Applications INCONEL C-276 is chiefly used in the following areas:
Products made using INCONEL C-276 are as follows:
|
