| Place of Origin: | China |
|---|---|
| Brand Name: | Bozhong |
| Certification: | ISO / TUV / DNV |
| Model Number: | 1.2323 / DIN 48CrMoV6-7 |
| Minimum Order Quantity: | negotiable |
| Price: | negotiable |
| Packaging Details: | seaworthy packing or as required |
| Delivery Time: | 3--10days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000TON/MONTH |
| Description: | Stainless Steel Sheet | Grade: | 1.2323 / DIN 48CrMoV6-7 |
|---|---|---|---|
| Dimension: | Accept Custom | MOQ: | Different |
| Standard: | AISI, ASTM, DIN, EN, GB ,JIS | ||
| High Light: | 400 plate,abrasion resistant sheet |
||
Designation by Standards
| Mat. No. | DIN | EN | AISI |
| 1.2323 | 48CrMoV6-7 | - | - |
Chemical Composition (in weight %)
| C | Si | Mn | Cr | Mo | Ni | V | W | Others |
| 0.45 | 0.25 | 0.75 | 1.45 | 0.75 | - | 0.30 | - | - |
Description
Oil-hardenable hot-work tool steel with normal heat resistance characteristics and high ductility, primarily for the processing of light metals. This steel grade can be water cooled.Applications
Tools for hot forging of light metals. Pressure casting tools, low stressed hot work tools, dies, mandrels, punchers, knives, moulds.Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.82Soft Annealing
Heat to 740-770oC, cool slowly. This will produce a maximum Brinell hardness of 215.Hardening
Harden from a temperature of 950-1000oC followed by oil quenching.Tempering
Tempering temperature: 550-650oC.Forging
Hot forming temperature: 1050-850oC.Machinability
No data.Disclaimer
