| Place of Origin: | China |
|---|---|
| Brand Name: | Bozhong |
| Certification: | IOS,SGS |
| Model Number: | 5052 Aluminum Alloy Plate |
| Minimum Order Quantity: | 300KG |
| Price: | USD1.2-3.5/KG FOB SHANGHAI |
| Packaging Details: | Standard Seaworthy Package |
| Delivery Time: | 7-25DAYS ACCORDING TO YOUR ORDER QUANTITY |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10000TONS PER MONTH |
| Alloy Or Not: | Alloy | Application: | Industry,Decoration,Signs |
|---|---|---|---|
| Type: | Plate,sheet,Decorations,Aluminum,Sublimation | Surface Treatment: | Coated,Embossed,Customer's Requirement,other |
| Width: | Customer Requirement,500mm-2800mm,70mm~1600mm,1220mm*2440mm*3mm/4mm/5mm | Grade: | 5052 |
| Material: | Aluminum Alloy | Temper: | H32 |
| High Light: | ASTM Aluminium Alloy Plate,H32 Aluminium Alloy Plate |
||
5052 aluminum plate is AL-Mg series alloy aluminum plate. Magnesium is the main alloying element in 5052 alloy aluminum plate. It is the most widely used anti-rust aluminum. This alloy has high strength, especially fatigue strength: plasticity and corrosion resistance. High performance, cannot be strengthened by heat treatment, good plasticity during semi-cold work hardening, low plasticity during cold work hardening, good corrosion resistance, good weldability, poor machinability, and polishing.
Aluminum-magnesium alloy also contains a small amount of manganese, chromium, beryllium, titanium and so on. Except for a small amount of solid solution, most of the manganese in the alloy forms MnAl6. The role of chromium in 5052 aluminum plate is similar to that of manganese, which improves the resistance to stress corrosion cracking, improves the strength of the base metal and the weld seam, and reduces the tendency of welding cracks, but its content generally does not exceed 0.35%.
| Aluminium Sheet / Aluminium Plate | ||
| 1 | Production Standard | ASTM, B209, JIS H4000-2006,GB/T2040-2012,etc |
| 2 | Material | 1000 2000 3000 4000 5000 6000 7000 8000 |
| 3 | Width | 50mm-2500mm or as the customer’s request |
| 4 | Longth | 50mm-8000mm or as the customer’s request |
| 5 | Thickness | 0.12mm-260mm |
| 6 | Surface | Coated, Embossed,Brushed, polished, Anodized,etc |
| 7 | OEM service | Perforated, Cutting special size, Doing flatness, Surface treatment,etc |
| 8 | Payterm | Ex-work, FOB, CIF , CFR, etc |
| 9 | Payment | T/T, L/C, Western Union, etc |
| 10 | Delivery Time | Within 3 days for our stock size,15-20days for our production |
| 11 | Package |
Export standard package: bundled wooden box, suit for all kinds of transport, or be required |
| 12 | MOQ | 200kg |
| 13 | Sample | Free and available |
| 14 | Quality | Certificate of Test,JB/T9001C,ISO9001,SGS,TVE |
| 15 | Export To | Ireland,Singapore,Indonesia,Ukraine,SaudiArabia,Spain,Canada,USA,Brazil,Thailand,Korea, Iran,India,Egypt,Kuwait,Oman,Viet Nam,South Africa,Dubai,England,Holland,Russia,etc |
| 16 | Application | Construction filed, Ships building industry, Decoration, Industry,Manufacture,Machinery and hardware fields, etc |
| Mechanical Property | ||||||||
| ALUMINUM ALLOY |
Grade | Normal Temper |
Temper | Tensile Strength N/mm² |
Yield Strength N/mm² |
Elongation% | Brinell Hardness HB |
|
| Plate | Bar | |||||||
| 1XXX | 1050 | O,H112,H | O | 78 | 34 | 40 | - | 20 |
| 1060 | O,H112,H | O | 70 | 30 | 43 | - | 19 | |
| Al-Cu (2XXX) |
2019 | O,T3,T4,T6,T8 | T851 | 450 | 350 | 10 | - | - |
| 2024 | O,T4 | T4 | 470 | 325 | 20 | 17 | 120 | |
| Al-Mn (3XXX) |
3003 | O,H112,H | O | 110 | 40 | 30 | 37 | 28 |
| 3004 | O,H112,H | O | 180 | 70 | 20 | 22 | 45 | |
| Al-Si (4XXX) | 4032 | O,T6,T62 | T6 | 380 | 315 | - | 9 | 120 |
| Al-Mg (5XXX) |
5052 | O,H112,H | H34 | 260 | 215 | 10 | 12 | 68 |
| 5083 | O,H112,H | O | 290 | 145 | - | 20 | - | |
| Al-Mg-Si (6XXX) |
6061 | O,T4,T6,T8 | T6 | 310 | 275 | 12 | 15 | 95 |
| 6063 | O,T1,T5,T6,T8 | T5 | 185 | 145 | 12 | - | 60 | |
| Al-Zn-Mg (7XXX) |
7003 | T5 | T5 | 315 | 255 | 15 | - | 85 |
| 7075 | O,T6 | T6 | 570 | 505 | 11 | 9 | 150 | |
