| Place of Origin: | China |
|---|---|
| Brand Name: | Bozhong |
| Certification: | IOS,SGS |
| Model Number: | Gr5 |
| Minimum Order Quantity: | 100KG |
| Packaging Details: | Standard Seaworthy Package |
| Delivery Time: | 7-25DAYS ACCORDING TO YOUR ORDER QUANTITY |
| Payment Terms: | T/T |
| Supply Ability: | 100TONS PER MONTH |
| Material: | Titanium Alloy Sheet /Bar | Processing Service: | Bending, Welding, Decoiling, Cutting, Punching |
|---|---|---|---|
| Standard: | AMS 4965 | Shape: | Sheet/Bar |
| Package: | Wooden Case | Technique: | Forging ,Machining Top |
| Grade: | Gr5,6AL4V | ||
| High Light: | Gr5 Titanium Alloy Sheet,6AL4V Titanium Alloy Sheet,AMS 4965 Alloy Steel Plate |
||
Ti -6Al-4V is heat treatable and has high strength and ductility along with good weldability and fabricability.
Round bars are available in the solutioned treated & aged condition in accordance with AMS 4965.
Special offer: 330 lbs - 1.525" dia x 12 ft r/l AMS 4965 (solution treated and aged - STA)
The chemical composition of grade 5 Ti-6Al-4V alloy is outlined in the following table.
| Element | Content (%) |
|---|---|
| Titanium, Ti | 87.6 - 91 |
| Aluminum, Al | 5.5 - 6.75 |
| Vanadium, V | 3.5 - 4.5 |
| Iron, Fe | ≤ 0.40 |
| Oxygen, O | ≤ 0.20 |
| Carbon, C | ≤ 0.080 |
| Nitrogen, N | ≤ 0.050 |
| Hydrogen, H | ≤ 0.015 |
The physical properties of grade 5 Ti-6Al-4V alloy are tabulated below.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 4.43 g/cm3 | 0.160 lb/in3 |
| Melting point | 1674 °C | 3045 °F |
The following table shows mechanical properties of grade 5 Ti-6Al-4V alloy.
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | ≥ 895 MPa | ≥ 130000 psi |
| Yield strength | ≥ 828 MPa | ≥ 120000 psi |
| Poisson’s ratio | 0.31 | 0.31 |
| Elastic modulus | 105-120 GPa | 15200-17400 ksi |
| Shear modulus | 41-45 GPa | 5950-6530 ksi |
| Elongation at break | ≥ 10 % | ≥ 10 % |
The thermal properties of grade 5 Ti-6Al-4V alloy are tabulated below.
| Properties | Metric | Imperial |
|---|---|---|
| Thermal expansion co-efficient (@0.000-100°C/32-212°F) | 9 µm/m°C | 5 µin/in°F |
| Thermal conductivity | 6.60W/mK | 45.8 BTU in/hr.ft².°F |
FAQ
Q:What are the advantages of your company?
A: We have many professional technical personnel.And we have more competitive prices and better after-sales service than other companies.
Q:How do you control the quality?
A:Our company is certificated to ISO9001.We have many inspectors and every product will have been tested for 4-5processes.We welcome customers or the third party inspection agencies to come to our factory for inspection.
Q:What about your price?
A:Our price is very competitive because we are a factory.Please contact us if you are interested in our products.
Q:How long is your delivery time?
A:Different products have different delivery time.The products will be delivered as soon as possible on the basis of the quality assurance.Usually the delivery time is within 20-25 days after we recieved your desipot.
