| Place of Origin: | China |
|---|---|
| Brand Name: | Bozhong Metal |
| Certification: | ISO GB TUV |
| Model Number: | 5052-O Aluminum Alloy Plate |
| Minimum Order Quantity: | 200kgs |
| Packaging Details: | pallet |
| Delivery Time: | 3--10days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 3000tons |
| Application: | Industry | Type: | Plate,sheet,Aluminum |
|---|---|---|---|
| Surface Treatment: | No | Width: | Customer Requirement |
| Product Name: | 5052-O Aluminum Alloy Plate | Shape: | Flat Plate |
| High Light: | 5052-O Aluminum Alloy Plate,Aviation Magnesium Aluminum Alloy Plate,TUV Aluminum Alloy Plate |
||
5052-O Aluminum Alloy plate / Sheet High Fatigue strength & High Tensile Strength
5052 aluminum plate is AL-Mg series alloy aluminum plate. Magnesium is the main alloying element in 5052 alloy aluminum plate. It is the most widely used anti-rust aluminum. This alloy has high strength, especially fatigue strength: plasticity and corrosion resistance. High performance, cannot be strengthened by heat treatment, good plasticity during semi-cold work hardening, low plasticity during cold work hardening, good corrosion resistance, good weldability, poor machinability, and polishing.
Aluminum-magnesium alloy also contains a small amount of manganese, chromium, beryllium, titanium and so on. Except for a small amount of solid solution, most of the manganese in the alloy forms MnAl6. The role of chromium in 5052 aluminum plate is similar to that of manganese, which improves the resistance to stress corrosion cracking, improves the strength of the base metal and the weld seam, and reduces the tendency of welding cracks, but its content generally does not exceed 0.35%.
This major series of this series aluminum pipe provided by Bozhong includes 5005, 5052, 5754, 5083 series.
5000 Series Aluminum pipe
Length:2000-8000mm
Application:decoration, outer shell for household products
Packing:blank waterproof paper , kraft, wooden case or pallet (fumigation report for the wooen packing material )
Grade:5005 5052 5083 5086 5154 5182 5251 5754 etc.
Features
Very good elongation, anticorrosion performance
5000 Aluminum pipe Features
The main ingredient of this series aluminum pipe is magnesium element and the content is between 3% and 5%. It is also called aluminum magnesium alloy. With its low density, it features high tensile strength and elongation. This series aluminum pipe is a commonly used and mature series in China.
5000 Aluminum pipe Applications With the same area of other series, the weight of this aluminum pipe is lighter. As a result, it is used in aviation, such as in the fuel tanks in airplanes. It is widely used in conventional industries. This aluminum pipe can be used in continuously casting and rolling. It can be hot rolled. As a result, it can be used in oxidation and deep processing.
| Grade | Chemical composition | ||||||||||
| Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Zr | ||
| 5019 | 0.4 | 0.5 | 0.1 | 0.10~0.6 | 4.5~5.6 | 0.2 | - | 0.2 | Mn+Cr:0.10~0.6 | 0.2 | - |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.50~1.1 | 0.1 | - | 0.25 | - | - | - |
| 5050 | 0.4 | 0.7 | 0.2 | 0.1 | 1.1~1.8 | 0.1 | - | 0.25 | - | - | - |
| 5251 | 0.4 | 0.5 | 0.15 | 0.10~0.50 | 1.7~2.4 | 0.15 | - | 0.15 | - | 0.15 | - |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2~2.8 | 0.15~0.35 | - | 0.1 | - | - | - |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6~3.6 | 0.3 | - | 0.2 | Mn+Cr:0.10~0.6 | 0.15 | - |
| 5056 | 0.3 | 0.4 | 0.1 | 0.05~0.20 | 4.55.6 | 0.05~0.20 | - | 0.1 | - | - | - |
| 5456 | 0.25 | 0.4 | 0.1 | 0.50~1.0 | 4.7~5.5 | 0.05~0.20 | - | 0.25 | - | 0.2 | - |
| 5082 | 0.2 | 0.35 | 0.15 | 0.15 | 4.0~5.0 | 0.15 | - | 0.25 | - | 0.1 | - |
| 5182 | 0.2 | 0.35 | 0.15 | 0.20~0.50 | 4.0~5.0 | 0.1 | - | 0.25 | - | 0.1 | - |
| 5000 series aluminum alloy sheet physical properties | |
| Tension strength | σb (MPa) ≥270 |
| Yield strength | σ0.2 (MPa)≥120 |
| temper | H32 H112 H111 H24 |
| Hardness | HB45-75 |
| Elongation | >12 |
Note:
Special dimensions can be produced according to your requirement
Bozhong is a professional manufacturer and supplier of 5000 aluminum pipe based in China. We also offer aluminum coil, aluminium slit coil, aluminum sheet, coated aluminum coil, diamond aluminum tread pipe,and more. Whenever you have a need for any of our products, please feel free to contact us.
