| Place of Origin: | China |
|---|---|
| Brand Name: | BOZHONG |
| Certification: | ISO / TUV / DNV |
| Model Number: | N08800 |
| Minimum Order Quantity: | 500KG |
| Price: | USD1.2-3.5/KG FOB SHANGHAI |
| Packaging Details: | seaworthy packing or as required |
| Delivery Time: | 3--10days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000TON/MONTH |
| Description: | N08800 Nickel Alloy Plate | Grade: | N08800 |
|---|---|---|---|
| Width: | 1000-2000mm | Density: | 7.94 Gm/cm3 |
| Tensile Strength(annealed): | 600 MPa | Standards: | ASME SB-409; AMS 5877 |
| High Light: | nickel alloy sheet,thin alloy sheet |
||
|
Introduction INCOLOY alloys belong to the category of super austenitic stainless steels. These alloys have nickel-chromium-iron as the base metals, with additives such as molybdenum, copper, nitrogen and silicon. These alloys are known for their excellent strength at elevated temperatures and good corrosion resistance in a variety of corrosive environments. INCOLOY alloy 800 is an alloy of nickel, iron and chromium. The alloy is capable of remaining stable and maintaining its austenitic structure even after long time exposures to high temperatures. Other characteristics of the alloy are good strength, and high resistance to oxidizing, reducing and aqueous environments. The standard forms in which this alloy is available are round, flats, forging stock, tube, plate, sheet, wire and strip. This datasheet will look into the chemical composition, properties and applications of INCOLOY 800. Chemical Composition The chemical composition of INCOLOY alloy 800 is given in the following table.
Physical Properties The following table discusses the physical properties of INCOLOY alloy 800.
Mechanical Properties The mechanical properties of INCOLOY alloy 800 are tabulated below.
Other Designations Some of the designations used to denote INCOLOY alloy 800 are listed below:
Fabrication Machinability Machining characteristics of this INCOLOY alloy 800 are similar to that of iron-based alloys. This alloy tends to work-harden during machining. Welding INCOLOY alloy 800 can be welded by common welding techniques, using a matching filler metal. Forming This alloy exhibits good ductility and hence can be formed using conventional methods. Hot working INCOLOY alloy 800 can be hot worked at temperature ranges of 871-1232°C (1600-2250°F). Cold Working Cold working may be done on the alloy using standard tooling. Annealing INCOLOY alloy 800 may be annealed after cold working. Annealing should be done at 982°C (1800°F) for 15 min and then the alloy should be air cooled. Applications INCOLOY alloy 800 is used in the following applications:
|
