| Place of Origin: | China |
|---|---|
| Brand Name: | Bozhong |
| Certification: | ISO / TUV / DNV |
| Model Number: | 1.3401 / DIN X120Mn12 / AISI A128 GradeA |
| Minimum Order Quantity: | negotiable |
| Price: | negotiable |
| Packaging Details: | seaworthy packing or as required |
| Delivery Time: | 3--10days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000TON/MONTH |
| Description: | Stainless Steel Sheet | Grade: | 1.3401 / DIN X120Mn12 / AISI A128 GradeA |
|---|---|---|---|
| Standard: | AISI, ASTM, DIN, EN, GB ,JIS | Dimension: | Accept Custom |
| MOQ: | Different | ||
| High Light: | alloy steel rod,steel bar stock |
||
Designation by Standards
| Brand Name | Ravne No. | Mat. No. | DIN | EN | AISI |
| 12MN | 901 | 1.3401 | X120Mn12 | - | A128 grade A |
Chemical Composition (in weight %)
| C | Si | Mn | Cr | Mo | Ni | V | W | Others |
| 1.20 | 0.40 | 12.50 | max. 1.50 | - | - | - | - | - |
Description
Austenitic Mn-steel. The well-known Hadfield steel still has broad applications in the mineral processing industry. Especially under impact loading Hadfield steel displays good wear resistance due to its high cold work ability. However, Hadfield steel is not corrosion resistant.
Applications
Components for dredgers and crushers, conveying machines: crushings jaws, impact wedges, linings, etc.
Forging
Hot forming temperature: 1050-850oC
Machinability
The machinability of this steel is poor.
Forms manufactured: Please see the Dimensional Sales Program.
Disclaimer
The information and data presented herein are typical or average values and are not a guarantee of maximum or minimum values. Applications specifically suggested for material described herein are made solely for the purpose of illustration to enable the reader to make his own evaluation and are not intended as warranties, either express or implied, of fitness for these or other puposes. There is no representation that the recipient of this literature will receive updated editions as the become available.
