| Place of Origin: | China |
|---|---|
| Brand Name: | BOZHONG |
| Certification: | IOS,SGS |
| Model Number: | K500 |
| Minimum Order Quantity: | 500KG |
| Packaging Details: | Standard Seaworthy Package |
| Delivery Time: | 7-25DAYS ACCORDING TO YOUR ORDER QUANTITY |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100TONS PER MONTH |
| Materials: | Monel | Grade: | K500 |
|---|---|---|---|
| Standard: | UNS N05500 | Shape: | Sheet/Bar/Pipe |
| Ni: | 63% | ||
| High Light: | UNS N05500 Alloy Steel Bar,Monel Alloy Steel Bar,K500 Grade Alloy Steel Bar |
||
Equivalent designations:
UNS N05500
DIN W. Nr. 2.4375
Monel Monel K-500 Trade Name: UNS N05500; W.Nr. 2.4375
| Form | ASTM |
| Rod, bar, sheet, wire and forging etc | B 865 |
Chemical composition
| % | Ni | Cu | Fe | C | Mn | Si | S | Al | Ti |
| min | 63.0 | 27.0 | 2.30 | 0.35 | |||||
| max | 33.0 | 2.0 | 0.18 | 1.5 | 0.50 | 0.010 | 3.15 | 0.85 |
Physical properties
| Density | 8.44 g/cm3 |
| Melting range | 1315-1350℃ |
Features:Monel K-500 combines Monel 400’s excellent corrosion resistance with greater strength and hardness as a result of adding aluminum and titanium and proper heat treatment to cause precipitation hardening. It is nonmagnetic at temperatures as low as -101℃. Monel K-500 has excellent dimensional stability which is very useful in high precision devices. Like Monel 400, it does not undergo ductile-to-brittle transition at cryogenic temperatures as low as that of liquid hydrogen. Its tensile and yield strengths increase while ductility and toughness are only slightly impaired.
Applications:Chemical process pump and valve components; paper production pulp processing doctor blades and scrapers; marine engineering chains, cables, fasteners and springs; electronic components; and oil and gas production non-magnetic housings, pump shafts and impellers.
