| Place of Origin: | China |
|---|---|
| Brand Name: | Bozhong |
| Certification: | ISO / TUV / DNV |
| Model Number: | 1.7337 / DIN 16CrMo4-4 / AISI A182 |
| Minimum Order Quantity: | negotiable |
| Price: | negotiable |
| Packaging Details: | seaworthy packing or as required |
| Delivery Time: | 3--10days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000TON/MONTH |
| Description: | Stainless Steel Sheet | Grade: | 1.7337 / DIN 16CrMo4-4 / AISI A182 |
|---|---|---|---|
| Standard: | AISI, ASTM, DIN, EN, GB ,JIS | Dimension: | Accept Custom |
| MOQ: | Different | Application: | For Steam Boilers And Turbines |
| High Light: | alloy steel rod,steel bar stock |
||
Description
Special structural steel.
Applications
Component parts for steam boilers and turbines, shafts for higher temperature ranges.
Physical properties (avarage values) at ambient temperature
Modulus of elasticity [103 x N/mm2]: 210
Density [g/cm3]: 7.85
Soft Annealing
Heat to 650-720oC, cool slowly in furnace.
Hardening
Harden from a temperature of 900-950oC followed by oil quenching.
Tempering
Tempering temperature: 650-720oC.
Forging
Hot forming temperature: 1100-850oC.
Machinability
No data.
Forms manufactured: Please see the Dimensional Sales Program.
