| Brand Name: | BOZHONG |
|---|---|
| Certification: | ISO / TUV / DNV |
| Model Number: | N06601/6023 |
| Minimum Order Quantity: | negotiable |
| Price: | negotiable |
| Packaging Details: | seaworthy packing or as required |
| Delivery Time: | 3--10days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000TON/MONTH |
| Description: | N06601/6023 Nickel Alloy Plate | Grade: | N06601/6023 |
|---|---|---|---|
| Thickness: | 4.76-60mm | Density: | 8.11 G/cm3 |
| Tensile Strength(annealed): | 760 MPa | MOQ: | 500KG |
| High Light: | nickel alloy sheet,thin alloy sheet |
||
|
Introduction Nicrofer 6023 alloy is a nickel-chromium-iron alloy with excellent resistance to corrosion and oxidation at elevated temperatures. The alloy is precipitation-hardenable, and exhibits good mechanical properties at high temperatures. The following datasheet will provide an overview of nicrofer 6023 alloy. Chemical Composition The chemical composition of nicrofer 6023 alloy is outlined in the following table.
Physical Properties The following table shows the physical properties of nicrofer 6023 alloy.
Mechanical Properties The mechanical properties of nicrofer 6023 alloy are displayed in the following table.
Thermal Properties The thermal properties of nicrofer 6023 alloy are given in the following table.
Fabrication and Heat Treatment Machinability Conventional machining techniques that are used for machining iron-based alloys can be used. Forming Nicrofer 6023 alloy has excellent ductility, and can be readily formed by all conventional techniques. Welding The alloy can be welded using commonly used welding techniques such as gas-tungsten arc welding, shielded metal-arc welding, gas metal-arc welding and submerged-arc welding. Forging The alloy can be forged in the temperature range of 1038 to 1232°C (1900 to 2250°F). Hot Working Hot working of nicrofer 6023 alloy can be performed in the temperature range of 871 to 1232°C (1600 to 2250°F). Cold working Cold working may be performed using standard tooling. Annealing The alloy can be annealed at 1149°C (2100°F) and then rapidly cooled to avoid thermal cracking. Other Designations Other designations that are equivalent to nicrofer 6023 alloy include the following:
Applications The following are the list of applications of nicrofer 6023 alloy:
|
